45
NOTE:
If the parking brake warning light is illuminated, the transmission
can not shift into forward or reverse. When the selector lever is in the
"F" or "R" position and the parking brake is on, the display blinks.
Release the parking brake and shift the selector lever to neutral (N)
position and then shift it again to forward (F) or reverse (R) in order to
drive.
For Manual Shift 2-Speed Automatic Transmission
When the manual shift 2-speed automatic transmission lever is in the
"1F" position, the displays appears as shown here.
When the manual shift 2-speed automatic transmission lever is in the
"2F" position, the displays appears as shown here.
NOTE:
UniCarriers does not recommend starting the lift truck from the second
speed position.
MALFUNCTION AND WARNING INDICATIONS
When a warning occurs, a warning symbol and the multipurpose
warning light illuminate. Following is an explanation of the meaning and
method of correction when a warning symbol illuminates.
MAST INTERLOCK WARNING
This warning illuminates when the ignition switch is turned on and the
operator is not seated on the seat or the operator leaves the seat for
three (3) seconds or more. Loading operation is prohibited at this time.
Loading becomes possible when the operator is seated on the seat.
NOTE:
Refer to page 82 for Seat belt Interlock options.
NR
C
E
H
F
F
Multipurpose warning lamp
Warning
