INSTRUMENTS AND CONTROLSINSTRUMENTS AND CONTROLS
2-192-19
ARMREST [1]ARMREST [1]
ASSIST GRIP [2]ASSIST GRIP [2]
When traveling the truck, put your right elbow on theWhen traveling the truck, put your right elbow on the
armrest with your right hand holding the assist grip. Thisarmrest with your right hand holding the assist grip. This
way, you can operate the truck more safely with lessway, you can operate the truck more safely with less
fatigue.fatigue.
MOTOR HOOD [3]MOTOR HOOD [3]
WARNINGWARNING
Make sure the cover is securely closed beforeMake sure the cover is securely closed before
starting the truck.starting the truck.
An incompletely locked cover might open whileAn incompletely locked cover might open while
operating, causing an accident.operating, causing an accident.
If you want to inspect or service the motor, drive unit orIf you want to inspect or service the motor, drive unit or
electromagnetic brake unit, open the motor hood.electromagnetic brake unit, open the motor hood.
The motor hood is locked in place with the knob bolt [4]The motor hood is locked in place with the knob bolt [4]
to the right of the operator’s seat. Remove the knob boltto the right of the operator’s seat. Remove the knob bolt
and open the motor hood.and open the motor hood.
To close the motor hood, return it to its original positionTo close the motor hood, return it to its original position
and tighten the knob bolt to lock the hood in place.and tighten the knob bolt to lock the hood in place.
22
11
33
44
< Open motor hood >< Open motor hood >
