Unico 3642 User Manual

Bulletin 30-20 — Page 6
© Copyright 2010, Unico, Inc.
Add insulation piece (centered on the panel). This is provided
with the MV2430 / MV3642 modules or UPC-63A / UPC-64A
conversion kits.
Trim insulation as shown.
Final panel assembly shown.
IL00302.
C
NV
Reposition Latches
to sides of Module
UPC-104-xxxx
Return Air
Adapter
Airflow
MV Vertical Heat
Module
AIRFLOW
UPC-104
Return Air Adapter
Typical Vertical
S
y
stem La
y
out
Gasket Tape
(Shipped Loose)
I
L
0
0
3
0
3
.
C
N
V
STEP 2. If using the UPC-104 Adapter, reposition the
latches to connect to the MV module.
Vertical
Heating
Module
Return Air
Adapter
Airflow
Latches
(shipped
loose)
Note: Attach Latches and Latch keepers to appropriate
modules o
n
o
p
p
osite side
(
n
ot s
h
ow
n
)
Gasket Tape
(applied to top
of MV module)
Cooling
Module
Latch Keeper
(shipped loose)
STEP 3. Place cooling module on top of vertical module.
Install latches and keepers as shown to secure the cooling
module.
NOTE: Attach insulation gasket tape along
the top opening of Cooling Module to en-
sure air-tight fit.
