20
2. Display of Date or Time
The instrument screen can either display date or time (hour:min:sec). Select Display
Mode in Fig. 30. Press 【∧】【∨】to select Display Time or Display Date. Press
ENTER to confirm. Press EXIT to return to Edit Clock screen.
3. Clock Trimming
This function is only useful when the clock is not running accurately. Set the off-set
level (clock trimming) to adjust the clock. There are 64 levels of adjustments:
Slow Levels Fast Levels
Slowest Fastest
32---------------------16-----------------------0 0-----------------------16---------------------32
Cable 1
Select Clock Trimming (Fig. 30), press 【∧】【∨】to set the adjustment level.
Press ENTER to confirm. Press EXIT return to Set Clock menu.
System Baseline: It is used for determining the appropriate energy level across the whole
wavelength range. The following LCD display shows establishing system
baseline in progress.
