Specifications
Certified in accordance with FCC Rules and Regulations Part 15,
Subpart C, as of date of manufacture.
Channel: 1000
Banks: 10 (100 channels each)
Service Bands: 12 preprogrammed search bands
(including the NOAA Weather
Service band)
Frequency Range: 25.0 - 27.995 MHz AM
28.0 - 53.99 MHz FM
54.0 - 71.95 MHz WFM
72.0 - 75.995 MHz FM
76.0 - 87.95 MHz WFM
88.0 - 107.9 MHz WFM
108.0 - 136.975 MHz AM
137.0 - 161.995 MHz FM
162.0 - 173.9875 MHz FM
174.0 - 215.95 MHz WFM
216.0 - 224.995 MHz FM
225.0 - 399.95 MHz AM
400.0 - 512.0 MHz NFM
806.0 - 823.9875 MHz NFM
849.0125 - 868.9875 MHz NFM
894.0125 - 956.0 MHz NFM
1240.0 - 1300.0 MHz NFM
Operating Temperature:
–
20 °C to
+
60 °C (–4°F to 140°F)
Scan Rate: 100 channels per second MAX.
(conventional mode)
Search Rate: 100 steps per second MAX.
(Normal Search)
300 steps per second MAX.
(Turbo Search)
Scan Delay: 2 seconds
Audio Output: 240 mW nominal
(8Ω internal speaker)
38 mW nominal
(32Ω stereo headphone)
9 mW nominal
(64Ω earphone)
Internal Speaker: 8 ohms (36 mm outer diameter)
Power Requirements: AD600U AC Adapter
(12V DC, 500mA)
or
4.8V DC 1500mAh (internal battery)
Antenna: Rubber Antenna (included)
Antenna Jack: BNC type
External Jacks: DC 12 V Power Jack
(center is positive)
Remote Jack
Earphone Jack
Size: 65mm (W) x 45mm (D) x 153mm (H)
Weight: 350 g (12 3/8 oz.)
Features and specifications are all subject to change without notice.
