[14]
Wall Mounting the Base
This phone can be mounted on any standard wall
plate.
1. Snap the wall mount adapter into the notches on the base top.
2. Plug the AC adapter into the jack.
3. Route the AC adapter cord through the molded wiring channel as
shown.
4. Plug the AC adapter into a standard 240V AC wall outlet.
5. Plug the telephone line cord into the jack.
6. Plug the telephone line cord into the telephone outlet.
7. Align the mounting slots on the base with the mounting posts on
the wall. Then push in and down until the phone is firmly seated.
use an AC outlet controlled by a wall switch.
DC IN 9V
TEL LINE
DO NOT
Notes:
Use only the supplied AAD-041S AC adapter.
Do not use any other AC adapter.
!
!
