5
Rear Panel Connectors
2
3
4
1
1. DC Jack
2. ACC Connector
3. Remote Connector
4. Antenna Connector
To OCEANUS DSC
Note: DC13.8V and GND are for GPS ANT.
ACC Connector
UT01910ZZ_0 9/18/03 5:37 PM Page 5
