TABLE 5 - SUMMARY OF STANDARD PARAMETER SETTINGS
NOTES
(*) These values are factory set - values must be set during operation at the plant based on the real working temperature/pres-
sure value.
WARNING
With pressure sensors, parameters SP1, SCH, SCL, HYS1, HYS3 must be selected and displayed in kPa (kilo Pascal).
(1bar = 100,000Pa = 100kPa)
PARAMETERS TO BE EDITED
SENSORS/PROBES C111 C113 SCL SCH SPL SPH HYS1 (*) HYS3 (*) Pb. 1 dt rt SP1 (*)
Siemens QAE2120.010 9030 0110 - - 30 95 -5 5 10 80 350 80°C
Siemens QAM2120.040 9030 0110 - - 0 80 -2,5 2,5 10 80 350 40°C
Pt1000 (130°C max.) 5030 0110 - - 30 95 -5 5 10 80 350 80°C
Pt1000 (350°C max.) 5030 0110 - - 0 350 -5 10 10 80 350 80°C
Pt100 (130°C max.) 0030 0110 - - 0 95 -5 5 10 80 350 80°C
Pt100 (350°C max) 0030 0110 - - 0 350 -5 10 10 80 350 80°C
Termocouple K A030 0110 - - 0 1200 -5 20 10 80 350 80°C
Danfoss/Siemens
4÷20mA p 1,6 bar
F030 0100 0 160 0 160 0 20 5 20 80 100kPa
Danfoss/Siemens
4÷20mA p 10 bar
F030 0100 0 1000 0 1000 0 50 5 20 80 600kPa
Danfoss/Siemens
4÷20mA p 16 bar
F030 0100 0 1600 0 1600 0 80 5 20 80 600kPa
Danfoss/Siemens
4÷20mA p 25 bar
F030 0100 0 2500 0 2500 0 125 5 20 80 600kPa
Danfoss/Siemens
4÷20mA p 40 bar
F030 0100 0 4000 0 4000 0 200 5 20 80 600kPa
Siemens QBE2.. P4 G030 0100 0 400 0 400 0 20 5 20 80 200kPa
Siemens QBE2.. P10 G030 0100 0 1000 0 1000 0 50 5 20 80 600kPa
Siemens QBE2.. P16 G030 0100 0 1600 0 1600 0 80 5 20 80 600kPa
Siemens QBE2.. P25 G030 0100 0 2500 0 2500 0 125 5 20 80 600kPa
Siemens QBE2.. P40 G030 0100 0 4000 0 4000 0 200 5 20 80 600kPa
Signal 0÷10V G030 to be fixed to be fixed to be fixed to be fixed to be fixed to be fixed to be fixed 5 20 80 to be fixed
Signal 4÷20mA F030 to be fixed to be fixed to be fixed to be fixed to be fixed to be fixed to be fixed 5 20 80 to be fixed
tt - servocontrol run
12 sec.
Servocontrol Berger STA12B…/Siemens SQN30.251/Siemens SQN72.4A4A20
tt - servocontrol run
13 sec.
Servocontrol Berger STA13B...
tt - servocontrol run
15 sec.
Servocontrol Berger STA15B...
tt - servocontrol run
30 sec.
Servocontrol Siemens SQL33.03/Siemens SQM10/Siemens SQM50/Siemens SQM54/Berger STM30../
Siemens SQM40.265
