PART I: SPECIFICATIONS
7
Technical SpecificationsTechnical Specifications
(*) NOTE ON THE BURNER WORKING SERVICE: LMV2x automatically stops after 24h of continuous working. The device immedia-
telystarts up, automatically. LMV3x performs countinuous operation.
Gas categories and countries of application
Fuel
BURNER TYPE G258A M-.. G335A M-.. G380A M-.. G400A M-..
Output min. - max. kW
165 - 2580 280 - 3350 295 - 3800 580 - 4000
Fuel
Natural gas
Category
(see next paragraph)
Gas rate- Natural gas
min.- max. (Stm
3
/h)
17,5 - 273 30 - 354 31 - 402 61 - 402
Gas pressure mbar
(see Note 2)
Power supply triphase
220 V/ 230 V 3~ / 380 V/ 400 V 3N ~ 50 Hz
Auxiliary Power supply
220 V/ 230 V 2~ / 220 V / 230 V 1N ~ 50 Hz
Total power consumption
kW 4,5 6 8
Electric motor
kW 4,0 5,5 7,5
Protection
IP40
Operation
Progressive - Fully modulating
Gas train 50
Valves size / Gas connection
50 / DN50
Gas train 65
65 / DN65
Gas train 80
80 / DN80
Gas train 100
100 / DN100
Operating temperature °C
-10 ÷ +50
Storage Temperature °C
-20 ÷ +60
Working service
Intermitent
Note1:
All gas flow rates are referred to Stm
3
/ h (1.013 mbar absolute pressure, 15 °C temperature) and are valid for G20 gas
(net calorific value H
i
= 34,02 MJ / Stm
3
); for L.P.G. (net calorific value H
i
= 93,5 MJ / Stm
3
)
Note2: Maximum gas pressure = 360 mbar (with Dungs MBDLE)
= 500 mbar (with Siemens VGD or Dungs MultiBloc MBE)
Minimum gas pressure = see gas curves.
Note3: Burners are suitable only for indoor operation with a maximum relative humidity of 80 %
GAS CATEGORY
COUNTRY
I
2H
AT, ES, GR, SE, FI, IE, HU, IS, NO, CZ, DK, GB, IT, PT, CY, EE, LV, SI, MT, SK, BG, LT, RO, TR, CH
I
2E
LU, PL
I
2E( R ) B
BE
I
2EK
NL
I
2ELL
DE
I
2Er
FR
DANGER! The burner must be used only with the fuel specified in the burner data
plate.
Type --
Model --
Year --
S.Number --
Output --
Oil Flow --
Fuel --
Category --
Gas Pressure --
Viscosity --
El.Supply --
El.Consump. --
