5
Setting the kind of sensor to be connected to the device:
push the Enter button: on the lower display (green) Opr appears. Using the up and down arrows find ConF. Push
Enter to confirm.
Now on the green display the group InP appears. Push Enter and InP1 is displaied. Enter to confirm.
You are inside InP1; the green display shows Sen1 (sensor type), while the red display shows the chosen sensor
code
Push Enter to enter the Sen1 parameter, then choose the desired sensor using the arrows. Push Enter to confirm
and ESC to escape.
Once selected the sensor, you can modify all the other parameters using up and down arrows according to the
tables here below.
ConF > InP >InP1
Parameter Value Description
SEn1
type of sensor for
analog input 1
1 Pt100 3 fili
2 Pt100 2 fili
3 Pt1000 3 fili
4 Pt1000 2 fili
5 Ni1000 3 fili
6 Ni1000 2 fili
7 0 ÷ 135 ohm
15 0 ÷ 20mA
16 4 ÷ 20mA
17 0 ÷ 10V
18 0 ÷ 5V
19 1 ÷ 5V
OFF1
sensor offset -1999..0.. +9999
Using the measured value correction (offset), a measured
value can be corrected to a certain degree, either up or down
SCL1
scale low level
-1999..0.. +9999
In the case of a measuring transducer with standard signal, the
physical signal is assigned a display value here
(for input ohm, mA, V)
SCH1
scale high level
-1999..100.. +9999
In the case of a measuring transducer with standard signal, the
physical signal is assigned a display value here
(for input ohm, mA, V)
dF1
digital filter 0…0,6…100
Is used to adapt the digital 2nd order input filter
(time in s; 0 s = filter off)
Unit
temperature unit
1
2
1 = degrees Celsius
2 = degrees Fahrenheit
(bold = factory settings)
Remark:
RWF50.2 e RWF50.3 cannot be connected to thermocouples.
If thermocouples have to be connected, convert the signal to a 4-20 mA one and set the RWF accordingly.
