Unigas G400A - Page 167

7
ConF > OutP (parameter under group only for RWF50.3)
Parameter Value Description
FnCt
tipo di controllo 1
4
1 = analog input 1 doubling with possibility to convert
(depending on par SiGn)
4 = modulation controller
SiGn
type of output signal
0
1
2
physical output signal (terminals A+, A-)
0 = 0÷20mA
1 = 4÷20mA
2 = 0÷10V
rOut
Value when out of
input range 0…101 signal (in percent) when measurement range is crossed
oPnt
zero point
-1999…0..+9999
value range of the output variable is assigned to a physical
output signal Per default, the setting corresponds to 0...100%
angular positioning for the controller outputs (terminals A+, A-)
(effective only with FnCt = 1)
End
End value
-1999…100..+9999
value range of the output variable is assigned to a physical
output signal Per default, the setting corresponds to 0...100%
angular positioning for the controller outputs (terminals A+, A-)
(effective only with FnCt = 1)
(bold = factory settings)
ConF > binF
Parameter Value Description
bin1
digital inputs
(terminals DG - D1)
0
1
2
4
0 = without function
1 = set-point changeover (SP1 / SP2)
2 = set-point shift (Opr > dSP parameter = value of set-point
modify)
4 = changeover of operating mode
open – modulating operation;
close – 2 stage operation.
(bold = factory settings)
ConF > dISP
Parameter Value Description
diSU
upper display
(red)
0
1
4
6
7
display value for upper display:
0 = display power-off
1 = analog input value
4 = Controller’s angular positioning
6 = set-point value
7 = end value with thermal shock protection
diSL
lower display
(green)
0
1
4
6
7
display value for lower display:
0 = display power-off
1 = analog input value
4 = Controller’s angular positioning
6 = set-point value
7 = end value with thermal shock protection
tout
timeout 0..180..250
time (s) on completion of which the controller returns
automatically to the basic display, if no button is pressed
dECP
decimal point
0
1
2
0 = no decimal place
1 = one decimal place
2 = two decimal places
CodE
level lockout
0
1
2
3
0 = no lockout
1 = configuration level lockout (ConF)
2 = Parameter and configuration level lockout (PArA & ConF)
3 = keyboard lockout
(bold = factory settings)
