Unigas G400A - Parameters summarising for RWF55.xx:

18
Parameters summarising for RWF55.xx :
NOTE:
(#) tt – servo control run time
SQL33 ; STM30; SQM10; SQM40; SQM50; SQM54 = 30 (secondi) - STA12B3.41; SQN30.251; SQN72.4A4A20 = 12 (secondi)
(*)These values are factory set - values must be set during operation at the plant based on the real working temperature/pressure value.
WARNING :With pressure probes the parameters SP1, SCH, SCL, HYS1, HYS3 must be selected, and visualized in kPa (kilo Pascal). (1bar = 100.000Pa = 100kPa)
ConF ConF
PArA Opr
Navigation menù Inp
Cntr diSP Inp1
Types of probe SEn1 OFF1 SCL SCH Unit SPL SPH dECP Pb. 1 dt rt tt HYS1 (*) HYS3 (*) SP1 (*)
  
Siemens QAE2120… 6 0 needless needless 1 30 95 1 10 80 350 (#) -5 5 80 °C
Siemens QAM2120.. 6 0 needless needless 1 0 80 1 10 80 350 (#) -2,5 2,5 40°C
Pt1000 (130°C max.) 4 0 needless needless 1 30 95 1 10 80 350 (#) -5 5 80°C
Pt1000 (350°C max.) 4 0 needless needless 1 0 350 1 10 80 350 (#) -5 10 80°C
Pt100 (130°C max.) 1 0 needless needless 1 0 95 1 10 80 350 (#) -5 5 80°C
Pt100 (350°C max) 1 0 needless needless 1 0 350 1 10 80 350 (#) -5 10 80°C
Probe 4÷20mA / 0÷1,6bar 16 0 0 160 needless 0 160 0 5 20 80 (#) 0 20 100 kPa
Probe 4÷20mA / 0÷3bar 16 0 0 300 needless 0 300 0 5 20 80 (#) 0 20 200 kPa
Probe 4÷20mA / 0÷10bar 16 0 0 1000 needless 0 1000 0 5 20 80 (#) 0 50 600 kPa
Probe 4÷20mA / 0÷16bar 16 0 0 1600 needless 0 1600 0 5 20 80 (#) 0 80 600 kPa
Probe 4÷20mA / 0÷25bar 16 0 0 2500 needless 0 2500 0 5 20 80 (#) 0 125 600 kPa
Probe 4÷20mA / 0÷40bar 16 0 0 4000 needless 0 4000 0 5 20 80 (#) 0 200 600 kPa
Siemens QBE2002 P4 17 0 0 400 needless 0 400 0 5 20 80 (#) 0 20 200 kPa
Siemens QBE2002 P10 17 0 0 1000 needless 0 1000 0 5 20 80 (#) 0 50 600 kPa
Siemens QBE2002 P16 17 0 0 1600 needless 0 1600 0 5 20 80 (#) 0 80 600 kPa
Siemens QBE2002 P25 17 0 0 2500 needless 0 2500 0 5 20 80 (#) 0 125 600 kPa
Siemens QBE2002 P40 17 0 0 4000 needless 0 4000 0 5 20 80 (#) 0 200 600 kPa
Signal 0÷10V 17 0 needless needless needless needless needless needless 5 20 80 (#)
Signal 4÷20mA 16 0 needless needless needless needless needless needless 5 20 80 (#)
