Chapter 2 Installation and Wiring
15
2.3 Module Flatness Adjustment
2.3.1 Module Flatness Adjustment
When there is a deviation in flatness between adjacent modules, use the
adjustment tool to adjust the magnet on the box. At the low end, the module regulates
the adjustable magnets until the module is flush with the adjacent modules. (one
module has 10 adjustable magnets)
Fig 2-22 Adjustable magnet Fig 2-23 Adjusting tool
Fig 2-24 Schematic diagram of adjustable magnet
