Chapter 7 Packaging Transportation and
Storage
7.1 Packaging
The ULW Ⅲ series products would be packed in carton, and the carton is
vacuum-packed in an anti-static bag, and finally packed in heavy-duty carton, as
shown below:
Figure 7-1 Package in Carton Figure 7-2 Package in Heavy-Duty Carton
7.2 Transportation
The cabinets must be packaged before transportation. The product shall not be
placed upside down or horizontally, and must be protected against the wind, rain, direct
sunlight, and corrosive liquid during transportation. The stacking layers shall not
exceed three layers for plywood cases.
7.3 Storage
The cabinets shall be stored in an environment with an ambient temperature
ranging from -20°C to +55°C and a relative humidity ranging from 10% to 85% RH. Do
not store the cabinets in an environment with volatile, corrosive, or flammable chemical
products.
