Chapter 3 LED Display Control Setting
34
5) Adjust Coefficient: Perform a simple adjustment if the displaying effect is not good
enough after you upload the coefficient. Then click Next.
Fig 3-19 Simple Adjustment
Red：Adjust the red brightness value of calibration coefficients.
Green：Adjust the green brightness value of calibration coefficients.
Blue：Adjust the blue brightness value of calibration coefficients.
6) Save Coefficients: Click Save to save the correction coefficients to the hardware.
The saved coefficients are retentive even after a power failure. Then click Finish.
Fig 3-20 Saving Correction Coefficients
