Page 10
POWERING TECHNOLOGY
Document No. M00035-MAN rev. 3a
aspiro1u_m35-man-rev3a-0417.indd
RECTIFIER MODEL XPGe12.48 XR08.48 XR04.48
Eciency 95% typical @ I
out
nom 90% typical @ I
out
nom 88% typical @ I
out
nom
Input Current (max) <7.3A <10.5A <5.3A
Output Current (max)
53.5V oat
22.4A 15.0A 7.5A
Output Power 1200W @ >180VAC
750W @ 90-180VAC
800W 400W
Operating Temperature
(without derating)
55°C 65°C 65°C
Input Voltage
(Nominal 100-240VAC)
90-300VAC 85-300VAC
Output Voltage 46-57VDC
Load sharing < 5% of nominal current
Dimensions (WxHxD) 40.6 (1.6”) x 101.62(4”) x 228.5(9”) mm
Weight 1.1 kg
Cooling Fan-cooled, speed and alarm controlled, air ow direction rear to front
Protection Short circuit proof, automatic current limiting, selective shutdown of modules at
excessive output voltage.
Alarms High output voltage/ shutdown, Low voltage/ module failure
LED Indication Green: Power ON
Yellow: Current limit/ thermal protection
Fan failure / Over temperature
Pre-warning / thermal protection
Communication Failure (ashing)
Red: Module failure / high output voltage shutdown
Audible noise <55dBA according to ISO7779
MECHANICAL
Dimensions (WxHxD) 480 mm x 44.45 mm x 266 mm
Weight of the system
(fully equipped)
6.5 kg
Mounting Options 19”/ ETSI / Mid-mount
Cable Entry Rear Access
STANDARD COMPLIANCE / ENVIRONMENTAL
EMC and Immunity ETSI EN 300 386 V.1.5
EN 55022
EN 55024, EN 61000-4
Safety EN 60950-1
Operating Temperature -40°C to +75°C, derating over +47°C (see appendix B)
Storage Temperature -40°C to +85°C
