2.3 System Parameters
OUTPUT
Power (max) 2400W @ >180VAC, 800W @ <180VAC
Output Current 52A max. @ 46VDC, 45A nominal (see appendix B)
15A (Low Power Shelf version with 20A shunt)
Voltage 46-57VDC
INPUT
Voltage 85-275VAC (Single-phase, 2 x Single-phase)
Frequency 50-60Hz
Input Current 16A (Single-phase), 8A (2 x Single-phase)
Power factor >0.98
DC DISTRIBUTION
Battery Breakers 1 x (AIRPAX, IER Series)
Ratings 40A, 50A, 65A
Load Breakers 4 x (NADER NDB3 Series)
Ratings* 1A, 4A, 5A, 7.5A, 10A, 15A, 20A, 25A, 30A
MONITORING AND CONTROL
Controller PCC or ACC Extended
Local Interface 4 x 20’ LCD, 4-key menu, USB (ACC only) and RS232
Remote Interface Ethernet / Modem using PowCom™ software
Visual Indication Green LED - System On
Yellow LED - Message(s)
Red LED - Alarm(s)
Analog Inputs 12 x voltage inputs (range 0-100VDC) - used for symmetry inputs
Analog Outputs 4 x potential free relays (C, NC, NO)
Digital Inputs 2 x, Logic 0: U<10VDC, Logic 1: U>12VDC
Digital Outputs 2 x, open collector type
Temperature measurement 2 x Temperature probe (Battery, Ambient)
CONNECTIONS
Battery connections Stripped cable, max.16mm
2
, spring type connector
AC connections Stripped cable with ferule, max. 2.5mm
2
, screw type connector
Load breaker connections Stripped cable with ferule, max. 4mm
2
, screw type connector
Alarm connections Stripped cable with ferule, max. 1.5mm
2
, screw type connector
* For load breaker derating limitations see chapter 3.2.5 Breakers on page 3-6.
