Unipower Aspiro 1U - Figure 4-7 Signal Pin Designations

Page 24
POWERING TECHNOLOGY
Document No. M00035-MAN rev. 3a
aspiro1u_m35-man-rev3a-0417.indd
7
7
8
8
9
9
4
4
5
5
6
6
1
1
2
2
3
3
X9
X10
Multipurpose 10 Multipurpose 11 Multipurpose 12
10 11 12 13 14 15 16 17 18 10 11 12 13 14 15 16 17 18
0V Sense +5V 0V Sense +5V
Battery
Temp.
Ambient
Temp.
Alarm 4 - C Alarm 4 - NC Alarm 4 - NO
Alarm 1 - C Alarm 1 - NC Alarm 1 - NO Alarm 2 - C Alarm 2 - NC Alarm 2 - NO Alarm 3 - C Alarm 3 - NC Alarm 3 - NO
Multipurpose 1 Multipurpose 2 Multipurpose 3 Multipurpose 4 Multipurpose 5 Multipurpose 6 Multipurpose 7 Multipurpose 8 Multipurpose 9
Digital In 1 Digital In 2 Digital Out 1 Digital Out 2 -
V Sys.
+V Sys.
Alarm Condition Shown
C
NC
NO
Figure 4-7 Signal Pin Designations
