Program the Output Sequence as:
1<CR>2,3<CR>5/4<CR>
Here <CR> is hexadecimal 0D if the bar code menu is used for setup. Scan CR from
full ASCII chart to get this character. Or press Ctrl-M if you use keyboard setup.
The last <CR> will not be necessary if Terminator is set to Enter.
For a card with following messages:
%B012345678901234^ABEL/STEVE L MGR ^90010129999999?
You will get:
012345678901234
ABEL, STEVE
01/90
The maximum number of characters that can be input in Track 1 Output Sequence is
16. If nothing is defined, all messages will be output.
2.8 Track 2 Output Sequence
The same implementation as Track 1 Output Sequence, but with the following
message-number match:
Message Number
Account Number 1
Expiration Year 2
Expiration Month 3
Discretionary Data 4
The maximum number of characters that can be input in Track 2 Output Sequence is 8.
If nothing is defined, all messages will be output.
2.9. Fix Length of 2 of 5 Codes
For Interleaved 2 of 5 and Standard 2 of 5 codes, specifying the decoding length is
strongly recommended. By using a fixed length (default), the keyboard will accept
lengths of first three I 2 of 5 or S 2 of 5 after powering up as valid decoding lengths.
If a bar code has a different length than the first three lengths, the keyboard will not
accept that label.
2.10. CLSI Format of Codabar
If selected, 14 characters Codabar (Start/Stop not included) will be output to CLSI
format with spaces inserted.
For example
