Unitech K2724 User Manual

Pin Number Signal
1 Start Of Scan
2 Data
3 Good Read
4 N/C
5 Switch Detect
6 Power Control
7 GND
8 VCC
6. Specification
Keyboard
Interface Enhanced AT, PS/2 keyboard
5-pin DIN / 6-pin mini DIN male coiled cable
Power Voltage: 5 VDC +/- 5%
Current: 250mA (including magnetic stripe reader)
Dimension (LxWxH) 400x210x43 mm (15.74x8.26x1.69 inches)
Net Weight 1.30 kg (2.86 lbs)
Operating Temperature: 0
o
C to 55
o
C
Humidity: 10% to 90% RH
Storage Temperature: -20
o
C to 55
o
C
Humidity: 10% to 95% RH
Magnetic Stripe Card Reader
Card Standard ISO 7811/2 through 5
Track Configuration Read ISO single track, dual track, Triple Track
Card Feed Bi-direction for ISO card
Card Swipe Speed 5 to 60 IPS (inch per second)
