All rights reserved 82 Service Manual e-Series (EN) 1.1.8
5.4 Backup of data
NOTICE
• When copying/moving files and folders, incorrect use might corrupt the file
system.
• Contact your IT professional for assistance if you are not comfortable with this
procedure.
This section explains the process of moving required files during a robot backup. From software
5.5 a backup/restore function is built into PolyScope. Please see User Manual or refer to section
5.1.3 on this manual.
5.4.1 Hardware Requirements
The following hardware is needed:
• SD Card (Universal Robots 4GB Industrial grade SD card)
• A standard SD card reader
5.4.2 Software Requirements
When using Windows operation system, to read a Linux partition a software file system driver is
required; in this example we are using “Linux File Systems for Windows” by Paragon but other
Windows Linux reader can be used as well (these are however not tested by Universal Robots).
NOTICE
“Linux File Systems for Windows” by Paragon software is a third-party software.
Universal Robot take no responsibility for this software.
5.4.3 How to Access Linux Partition from Windows
With the software from Paragon you can access all partitions on the SD-card.
The files needed are located on the partition called datafs
If the partition is not shown, it could be it is not mounted automatically.
To correct this, open the Paragon software, select the partition (1), select the Mount icon (2), select
the Volume drive letter (3) then Mount (4).
