All rights reserved 85 Service Manual e-Series (EN) 1.1.8
6.2 Support Log Reader(SLR)
Open log files with the Universal Robots Support Log Reader(SLR).
Go to www.universal-robots.com/support to download the Support Log Reader
1. Filter;
Select what filter to activate
= Info filter
= Warning filter
= Error filter
2. Tool bar;
Load log files, export error codes, change language
3. Text search;
Type error code or text
4. Log start Info bar*;
Created every time the robot is powered on.
5. Highlighted text;
When tapped, gives more detailed Information.
6. PolyScope time
7. Reporter;
Where the info is reported from ”safety, PolyScope, etc.”
8. Message;
Text with the Cxxxx refers to the error codes.
9. Log Entries;
Shown and total
10. Expand or collapse all Info bars (point 4)
Note: After loading the log file every Log Start Info Bar (4) is collapsed and only the summary for each log start is visible.
