Universal Robots CB Series Manual

6. Remove the top lid.
7. Now the power plug on the inside needs to be disconnected from the frame, how to do this
correctly is shown in Step 8.
8. For removing the power plug, you will need a small 2mm flathead screwdriver. Pull in the
power plug AND tip the two front locks upwards at the same time
9. Remove all connections to the Control Board.
e-Series 54 Service Manual
Copyright © 2009–2024 by UniversalRobotsA/S. All rights reserved.

Universal Robots CB Series Specifications

General

Brand	Universal Robots
Model	CB Series
Category	Robotics
Language	English
