NOTICE
The washer, when present, need to have the spikes facing downwards.
NO. DESCRIPTION Tool size Torque
1 Bolt and nut for fan and energy eater Torx T20/7mm 0.6Nm
2 Panel screw and washer Torx T20 1.6Nm
3 Robot connector screw Torx T20 1.6Nm
4 Shield connecting bold and washer 10mm 2.25Nm
NO. DESCRIPTION Tool size Torque
1a AC external power terminal screws PZ2 1.2Nm
Service Manual 59 e-Series
Copyright © 2009–2024 by UniversalRobotsA/S. All rights reserved.
