Unox MINDMaps CHEFTOP User Manual

P38
1
BLW2
24VDC
2 Input tachometer blower 2
3 Output control blower 2 - PWM (0-24Vdc) @4kHz
4
GND (ground connection)
P8
RJ PL UG 8
contacts 90°
1
-
+13V
Accessory board 1 connection (MODBUS)
2 GND
3 A
4 B
5
+12V
6
GND
7 GND
8 +13V
P9
RJ PLUG 8
contacts 90°
1
-
+13V
Accessory board 2 connection (MODBUS)
2 GND
3 A
4 B
5
+13V
6
GND
7 GND
8 +13V
P10
RJ PLUG 8
contacts 90°
1
-
+13V
Accessory board 3 connection (MODBUS)
2 GND
3 A
4 B
5
+13V
6
GND
7 GND
8 +13V
P11 CPM 4P-5P08
1
CONTROL
+13V
2 B
3 A
Control board connection (CANBUS)
4 GND
P12
1 +13V
2 B
3 - A
Bridge board connection (CANBUS)
4 GND
P13
1 +13V
2 B
3 - A
Bridge board connection (CANBUS)
4 GND
P28
AMP Modu II
6P
1
Potentially free contact 1
2
GND (ground connection)
3
Potentially free contact 2
4
GND (ground connection)
5 -
Potentially free contact 3
6
GND (ground connection)
2
P14 CPM-5P-3P81
1 IN1
2 IN2
3
MultiPoint IN3 Multi point core probe input
4 IN4
5 GND
MOLEX
Microfit
4P
MOLEX
Microfit
4P
MOLEX
Minifit 4P 2F
116
