Communication socket
Power board comes with:
■ 1 CANBUS socket to communicate with the control board (P11)
■ 2 CANBUS sockets to communicate with another power board and with a CANBUS-ETHERNET (P12, P13)
■ 3 MODBUS sockets doors to communicate with accessory power board (P8, P9, P10)
■ Power supply
PARAMETER NOMINAL VALUE MINIMUM VALUE MAXIMUM VALUE
NETWORK VOLTAGE SUPPLY
230 V
AC
180 V
AC
270 V
AC
NETWORK FREQUENCY
SUPPLY
- 50 Hz 60 Hz
PRIMARY TRANSFORMER
VOLTAGE
230 V
AC
180 V
AC
270 V
AC
SECONDARY TRANSFORMER 1
VOLTAGE
21 V ~ - -
SECONDARY TRANSFORMER 2
VOLTAGE
12 V ~ - -
SECONDARY TRANSFORMER 1
CURRENT
4.2 A - -
SECONDARY TRANSFORMER 2
CURRENT
83 mA - -
Socket table
T
SOCKET TYPE  LABEL DESCRIPTION
P1
INARLOCK 6P 2F
(White)
1 N
Board power supply (neutral)
2 N_F
3 L_F
Transformer power supply (phase)
4 L Board power supply (phase)
5 COND Capacitor for the motor startup
6 COND Capacitor for the motor startup
P2
INARLOCK 5P 1F
(Black)
1 N Neutral
2 RW Motor power supply -counterclock wise spinning
3 FW Motor power supply -clock wise spinning
4 F Phase 230 Vac
5 TM Motor thermal protection input
P3
INARLOCK 3P 1F
(Black)
1
RES1 Braking element 1
2
2
RES2 Braking element 2
3
P4
INARLOCK 6P 1F
(White)
1 PD
Detergent pump phase
2 N Detergent pump neutral
3 EL1
W
ater solenoid valve EL1 phase
4 N
Water solenoid valve EL1 neutral
5 VENT
DRY.Maxi phase
6 N
DRY.Maxi output neutral
Transformer power supply (filtered neutral)
26
