P25
INARLOCK 4P 1F
(Black)
1 EG2
EG2 solenoid phase
2 N
EG2 solenoid neutral
3 PS -
4 N -
P26
INARLOCK 4P 1F
(White)
1 EL2
EL2 solenoid phase
2 N
EL2 solenoid neutral
3 EG1
EG1 solenoid phase
4 N
EG1 solenoid neutral
P5
INARLOCK 3P 1F
(White)
1 EV1
EV1 Phase low flow rate
2 N
Common neutral output EV1 and EV2
3 EV2
EV2 Phase high flow rate
P6
INARLOCK 2P 1F
(Black)
1 FAN Cooling fan output - phase
2 N
Cooling fan output – neutral
P7
INARLOCK 2P 1F
(White)
1 ABB
Drainage cooling water solenoid phase
2 N
Drainage cooling water solenoid neutral
P8
RJ PLUG 8 contacts
90°
1
-
+13V
Accessory board 1 connection
(MODBUS)
2 GND
3 A
4 B
5 +12V
6 GND
7 GND
8 +13V
P9
RJ PLUG 8 contacts
90°
1
-
+13V
Accessory board 2
connection (MODBUS)
2 GND
3 A
4 B
5 +13V
6 GND
7 GND
8 +13V
P10
RJ PLUG 8 contacts
90°
1
-
+13V
Accessory board 3
connection (MODBUS)
2 GND
3 A
4 B
5 +13V
6 GND
7 GND
8 +13V
P11 CPM 4P-5P08
1
CONTROL
+13V
Control board connection
(CANBUS)
2 B
3 A
4 GND
34
