P24 1 ÷ 6 - -
P31
1
-
+13V
-
2 SR1
3 +13V
-
4 SR2
5 +13V
-
6 GND
P32 JST XHP-2
1
PRES
IN
Pressure switch potential
free input
2 GND GND
P40
1
-
Phase to the blower
2 Neutro to the blowers
E1 1 E1 Ground connection
Fuse list
Mechanical dimensions
DIMENSION X
420 mm
DIMENSION Y
145 mm
MAXIMUM HEIGHT
49 mm
FIXING HOLES DIAMETER
4,06 mm
Working parameters
PARAMETER MINIMUM VALUE MAXIMUM VALUE
WORKING TEMPERATURE +10 °C +70 °C
STORAGE TEMPERATURE -10 °C +70 °C
WORKING HUMIDITY - 80%
STORAGE HUMIDITY - 90%
Regulations
Reference Guidelines:
73/23/CEE
low voltage: electromagnetic compatibility:
89/336/CEE
General reference rule:
CEI EN50081-1
electromagnetic compatibility - emission:
electromagnetic compatibility - immunity:
CEI EN50082-1
FUSE
NOMINAL
CURRENT
NOMINAL
VOLTAGE
SPEED OF
INTERVENTION
PROTECTED CIRCUIT
F2 2A 250 V Fast (F) Primary transformer (TR60 230V-12V 60VA)
F3 2A 250 V Fast (F)
Detergent pump (PD output on P4 socket)
F4 4A 250 V Time delay (T) Secondary transformer (TR60 230V-12V 60VA)
F7 2A 250 V Fast (F) Gas control unit BRAHMA ECM113
F9 2A 250 V Fast (F) Blower gas premix
Line connection for
Blowers and flame
control board
Fixing screw
The PE2022A circuit board has been designed and built in order to fulfill the following legislations:
MOLEX Microfit 6P
MOLEX Microfit 6P
36
