Single rotor arm CHEFTOP-BAKERTOP MIND.Maps™, ONE ovens
The MIND.Maps
TM
ONE ovens have one rotor arm and have a washing circuit as illustrated below. T
he
washing circuit compared to plus models is much simpler as the washing circuit doesn’t have a pressure
switch and has the single rotor arm that only cleans the cooking chamber.
/01
/0-
VNR
FDET
VNR
PD
DETERGENT
TANK
P
S3
FDET
PD
EL2
G1
FAN GUARD
SHOWER
PROVER
HOOD
DRAIN
ROTOR ARM
EG1
550 mm
550 mm
EL1
R
EL1
L4 UP
120mm
670mm
50mm
170mm
/01
/0-
VNR
FDET
VNR
PD
DETERGENT
TANK
P
S3
FDET
PD
EL2
G1
FAN GUARD
SHOWER
PROVER
HOOD
DRAIN
ROTOR ARM
EG1
550 mm
550 mm
EL1
R
EL1
L4 UP
120mm
670mm
EV
DRAIN COOLING KIT
ABB
50mm
170mm
220mm
EG1

US and Japan oven
single rotor arm
European oven
single rotor arm
77
