Washing Cycles
The washing steps differ from model to model and from one washing program to another.
All the long programs follow the same steps.
Below shows the long washing program for 2 rotor arms for Plus models. This is similar to all models and
washing programs.
The Long washing program with 2 rotor arms following the below steps;
1) Prediagnostic: The washing valves are opened and closed multiple times in order to unblock them
from the possible presence of dirt or limescale.
2) Diagnostic: The opening and closing of the washing valves are checked with the pressure switch and if
the pressure switch doesn’t measure the desired value, a warning pops up in the control panel.
3) A
4) A* opposite sense of rotation
5) C
6) Final Rinse
7) Drying

Long washing program for 2 rotor arm for Plus models
A A* C
1 #1 Activating EG1 + Det
Pump
Residual Detergent
Rinsing
#1 Activating EG1 + DET Pump
2 #1 Activating EG2 + Det
Pump
Short standby
for
Chemic
al reaction
o
f the Det
ergent t
o
remo
v
e dirt
#1 Activating EG2 + DET Pump
3
#1 Activating EL2 + Det
Pump
EV1-EV2 Rinse #1 Activating EL2 + DET Pump
4
Standby for chemical
reaction of the Detergent
to remove dirt
EG2 Rinse
Standby for chemical reaction of
the Detergent to remove dirt
5
#2 Activating EG2 + Det
Pump
EL2 Rinse Steaming
6
#2 Activating EG1 + DET Pump
7
#2 Activating EG2 + DET Pump
8 #2 Activating EL2 + DET Pump
9
Standby for chemical reaction of
the Detergent to remove dirt
10 Steaming
11 Residual Detergent Rinsing
12
Short standby for Chemical
reaction of the Detergent to
remove dirt
13 EV1-EV2 Rinse
14 EG2 Rinse
15 EL2 Rinse
16 EG1 Rinse
82
