Heating Element
■ 2 braking elements per motor, 100 W and 147 W
SPIDO.Gas™ system
■ New spiral baffle design
■ Heat exchangers thickness increased from 15/10
mm to 20/10 mm
■ Every BIG gas oven has two blowers,
The gas supply for GN2021 and 16FS is increased
from ¾’’ to 1’’ while GN2011 and 16EU remain same
as ¾’’.
¾’’ 1’’
Six motors for PLUS range
■ An extra motor-fan group has been introduced on plus ovens,
■ Same asynchronous single-phase motor and same 8-blade fan group,
■ Fan guard thickness has increased from 10/10 to 12/10 mm in AISI 316L
Solenoid Actuator
Single collector
DRY.Maxi™ system
The diameter of the venturi pipe from the motor
increased from 16 mm to 20 mm, and with a single
collector, the pipe is 50 mm
in diameter.
Besides the extraction pipe, there are two solenoid
actuators with, each valve is connected to a
cooling fan.Humidity extraction speed increase
by 88% and reduced the time required to remove
the humidity by 50%
■ New heating element design:
- Configuration for GN 1/1 - 16 EU4 x 6625 W linear heating element
- Configuration for GN 2/1 - 16 FS 4 x 9000 W linear heating element
