UP Plus 2 User Manual

UP Plus 2 3D Printer User Manual v 2013.10.24
3. Quick Step by Step Setup Guide
1. Remove the two packing clips that hold the extruder head
and platform in place during shipping.
(keep these for when you move your printer)
2. Attach the “roll holder / feeder guide” onto the left side
of the printer.
3. Open the foil bag that contains the ABS filament.
NOTE: Do not let go of the end of the fila-
ment, otherwise it will unravel itself and tie itself in a
knot, which will then cause a block in the extruder
head and several hours of unwinding the spool manu-
ally to find the knot!
4. Load the spool of filament onto the roll holder, with the
filament coming out from the back of the roll / printer.
Do not let go of the end of the filament!

UP Plus 2 Specifications

General

Nozzle Diameter	0.4 mm
Filament Diameter	1.75 mm
Print Material	ABS, PLA
Connectivity	USB
Print Technology	Fused Filament Fabrication (FFF)
Supported OS	Windows, Mac OS X
Print Speed	10-100 mm/s
Power Requirements	110-240V, 50-60Hz
Weight	5 kg
Build Volume	140 x 140 x 135 mm
