UP Plus 2 3D Printer User Manual v 2013.10.24
9.6 Print Preferences
Click menu “3D Print->Setup” or Click “print” and select “Preferences’ and the following dialog
box opens:
Recommended Settings in red and in most cases are the only values that require changing de-
pending on the model you are printing.
Windows version Mac version
Z Resolution:
Sets the print resolution (layer thickness) of the printer. This can be between 0.2mm per layer to
0.4mm per layer. The finer the layer thickness, the better quality, the stronger the printed part and
the longer it takes to print.
Fill:
There are four types of honeycomb fill that the interior of parts are made of. These cut away im-
ages below show the four different internal fill types.
Solid Honeycomb: The part is made of nearly solid
plastic, which gives you the strongest part with a
longer print time. This setting is recommended for
strong and functional parts.
