Page 6-34
Illustrated Parts Breakdown -6.1-Introduction
MX15/19
Label Installation, MX19
065712-030
ITEM PART DESCRIPTION QTY.
1 061683-004 LABEL UPRIGHT 2
2 061684-023 LABEL MX 19 2
3 061683-014 LABEL UPRIGHT 2
4 066550-000 LABEL DANGER 1
5 060577-004 ANSI MANUAL 1
6 010076-000 MANUAL CASE 1
7 060570-004 USER MANUAL MX15/19 1
8 011248-004 LOCKNUT1/4-20UNC HEX 4
9 011252-006 SCREW 1/4-20UNC HHC X 3/4 4
10 011240-004 WASHER 1/4 STD FLAT 4
11 066559-000 LABEL CONTROLS 1
12 101251-000 LABEL MAX LOAD DECK EXT1
13 066552-000 LABEL WARNING 2
14 066553-003 LABEL WARNING KEEP CLEAR 2
15 066554-000 LABEL CAUTION 1
16 066555-000 LABEL CAUTION 1
17 066556-000 LABEL CAUTION 1
18 101250-000 LABEL MAX LOAD PLATFORM 2
19 066558-000 LABEL EMERG. LOWERING 1
20 101222-004 LABEL CONTROLLER 1
22 05221-000 LABEL BATTERY 2
23 14222-003-99 LABEL FORK-LIFT HERE 1
25 063255-001 LABEL SCISSOR BRACE 1
26 010076-001 LABEL INST. 1
27 061220-002 LABEL ANSI 1
28 101252-002 LABEL WHEEL MAX LOAD WHEEL 1
29 061205-005 NAME PLATE 1
30 065368-000 TACK 4
31 064444-000 LABEL USA 4
32 060830-003 SAFETY WALK 6 X 20 1
33 060830-002 SAFETY WALK 8 X 36 3
34 060830-001 SAFETY WALK 4 X 20 3
35 062562-001 LABEL DANGER 2
36 066522-000 LABEL BATTERY CHARGER 1
37 066556-001 LABEL WARNING 4
39 068639-000 LABEL POWER TO PLATFORM 1
40 107051-000 BATTERY DISCONNECT 1
ITEM PART DESCRIPTION QTY.
060569-004
