Page 3-9
Maintenance 3.8 - Motor Controller and I/O Board Dip Switch Settings
MX15/19
3.8 M
OTOR
C
ONTROLLER AND
I/O B
OARD
D
IP
S
WITCH
S
ETTINGS
NOTE: Before dip switch settings will take effect, power must be disconnected or Emergency Stop
switches must be depressed.
C
ONTROLLER
Figure 3-11:
Controller
The above table shows the default dip switch settings on
the controller box when the machine leaves the factory.
The following adjustments may be made to these set-
tings:
Switches 3 & 4 determine the elevated “creep” speed. If the
machine does not operate at the specified speed at the
default settings, use the following table to adjust the dip
switch settings
.
Switches 5 & 6 determine the deceleration time. Switch 5 is for the deceleration rate while the platform
islowered.Switch6isfortheelevatedrate.
I/O B
OARD
Figure 3-12:
I/O Board
The above table shows the default dip switch settings on the I/O
board when the machine leaves the factory. Switches 1 and 2
should not be changed. Switches 3 and 4 work together to deter-
mine the optional alarm settings
.
1 2 3 4 5 6 7 8
off on off on off on off on
3 4
1(slowest) off off
2onoff
3 (default) off on
4 (fastest) on on
Deceleration Speed 5 6
.24 sec. off off
1.27 sec. on on
1 2 3 4
off off off off
3 4 Result
off off Down alarm only
on off Down and Reverse alarm
off on Drive and Down alarm
on on All Motion alarm
1234
8765
1234
8765
1234
12 11 10 9
56
87
1234
12 11 10 9
56
87
1234
8765
4321
Part
No.
Serial
No.
4321
