Upright MX19 - Page 108

Page 6-36
Illustrated Parts Breakdown -6.1-Introduction
MX15/19
Removable Controller Option
061898-010
1 065926-010 PLUG CONNECTOR 1
2 068762-000 PIN CONTACT 15
3 068764-000 PLUG SEALING 16
4 065926-015 RECEPTACLE CONNECTOR 1
5 068762-001 SOCKET CONTACT 15
8 030719-001 110 VAC BRACKET 1
9 030719-002 AIR BRACKET WELDMENT 1
10 011254-018 SCREW HHC GRD5 3/8-16UNC X 21/4 4
11 011240-006 WASHER 3/8 STD FLAT 4
12 011248-006 NUTHEX ESNA 3/8-16 2
060569-004
