Upright MX19 - Page 111

Page 6-39
Illustrated Parts Breakdown -6.1-Introduction
MX15/19
Operator Horn Assembly
066614-020
ITEM PART DESCRIPTION QTY.
1 CONTROL MODULE ASSEMBLY REF
2 066807-002 HORN, 24 VDC 1
3 066805-018 SWITCH, PUSH BUTTON 6E 1
4 066805-010 CONTACT BLOCK NO 1
5 029620-002 CONNECTOR, BUTT 16-14 GA 1
6 029601-013 CONNECTOR, RING TERMINAL 4
7 029453-099 WIRE, 16 AWG BLUE4FT
8 029452-099 WIRE, 16 AWG BLACK 4FT
9 CONTROLLER ASSY REF
10 011252-006 SCREW HHC 1/4-20 X 3/4 1
ITEM PART DESCRIPTION QTY.
060569-004
