Upright MX19 - Page 82

Page 6-10
Illustrated Parts Breakdown -6.1-Introduction
MX15/19
Basic Assembly, MX15
065601-020
ITEM PART DESCRIPTION QTY.
1 065602-020 CHASSIS ASS’Y 1
2 065605-020 SCISSOR ARM ASS’Y X15 1
3 066250-001 PLATFORM WELDMENT 1
4 065698-000 LOWER PIVOT PIN WELDMENT 4
5 065726-000 SLIDE PAD 8
6 065728-000 DECK BRACKET L.H. 1
7 065727-000 DECK BRACKET R.H. 1
8 014027-006 SCREW HHD SLFTP 1/4-28 x 3/4 4
9 011739-020 ROLLPIN 3/8 DIA. x 2 1/2 4
10 014066-008 SCREW SLFTP 1/4-28 X 18
11 065754-006 EMERGENCY LOWERING CABLE 1
12 065937-001 BEARING RETENTION ANGLE 2
13 011254-034 SCREW HHC 3/8-16UNC X 41/4 2
14 011254-014 SCREW HHC 3/8-16UNC X 13/4 4
15 011240-006 WASHER 3/8 STD FLAT 4
16 011248-006 NUTHEX ESNA 3/8-16UNC 6
17 011829-022 CARRIAGE BOLT 1/4-20 X 2-3/4 PLATED 2
18 011786-007 MACHINERY BUSHING 1-1/2 X 14 GA. 2
19 011248-004 LOCK NUTHEX 1/4-20 2
21 065764-000 SCISSOR CHOCK WELDMENT X15/19 1
060569-004
