Upright MX19 - Page 92

Page 6-20
Illustrated Parts Breakdown -6.1-Introduction
MX15/19
Scissor Linkage Assembly, MX19
065705-020
ITEM PART DESCRIPTION QTY.
1 065640-001 INNER ARM WELDMENT 1
2 065671-000 OUTER BEAM WELDMENT R.H. 2
3 065672-000 OUTER BEAM WELDMENT L.H. 2
4 065675-000 OUTER BEAM WELDMENT 4
5 065677-000 INNER CENTER BEAM WELDMENT 1
6 065687-000 CABLE GUIDE 1
7 065696-000 CYLINDER PIN WELDMENT 1
8 065697-000 PIN KEEPER WELDMENT 2
9 065721-000 UPPER BEAM WELDMENT 1
10 065372-020 LIFT CYLINDER 1
065372-012 SEAL KIT
11 011248-004 LOCKNUT1/4-20UNC HEX 1
12 066183-002 BUSHING 20
14 011253-024 SCREW 5/16-18UNC HHC X 34
15 011253-022 SCREW 5/16-18UNC HHC X 23/4 16
16 011254-026 SCREW 3/8-16UNC HHC X 31/4 2
17 011248-005 LOCKNUT 5/16-18UNC HEX 20
18 065722-000 INNER BEAM WELDMENT 1
19 065688-000 GUARD RIVET 2
20 065750-000 CYLINDER PIN WELDMENT 1
21 011248-006 LOCKNUT3/8-16UNC HEX 2
22 012004-004 PLUG #41
23 012004-006 PLUG #61
24 065920-000 PIVOT PIN WELDMENT 18
25 066179-000 VALVE 1
26 011941-005 FITTING 6MB-6MJ ST 1
27 015919-001 ORIFICE 1
28 05133-000 SPRING 1
29 013919-009 CLAMP 4
060569-004
