Page 6-26
Illustrated Parts Breakdown -6.1-Introduction
MX15/19
Hose Kit Installation
065611-021
ITEM PART DESCRIPTION QTY.
1 101244-037 HOSE ASSY 3/8 X 37 (6FJX-6FJX)1
2 101243-034 HOSE ASSY 3/8 X 34 (6FJX-6FJX X 90) 2
3 068965-150 HOSE ASSY 3/8 X 150 (6FJX-6FJX X 90) 1
5 068965-013 HOSE ASSY 3/8 X 13 (6FJX-6FJX X 90) 1
8 107091-054 HOSE ASSY 3/16 X 54 (4FJX-4FJX X 90) 1
11 107090-031 HOSE ASSY 1/4 X 31 (4FJX-4FJX X 90) 2
12 061351-045 HOSE ASSY 1/8 X 13 (4FJX-4FJX)1
14 061789-017 HOSE ASSY 3/4 X 17 1/2 (12FJX-12MP) 1
15 064156-021 HOSE ASSY 1/2 X 42 (8FJX-8FJX)1
17 107091-038 HOSE ASSY 3/16 X 38 (4FJX-4FJX90) 1
19 107091-032 HOSE ASSY 3/16 X 32 1
20 107091-037 HOSE ASSY 3/16 X 37 2
060569-004
