Page 20 113100-020 - MX15 / MX19 - Operation Manual
Specifications
S
PECIFICATIONS
Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Parts Manual and the Service Manual for complete parts and service information.
The MX15 / MX19 meets or exceeds all applicable CE machinery directive requirements.
ITEM MX15 MX19
Platform Size (Inside minimum)
Standard w/Deck
0,72 m x 2,5 m (28.5 in. x 100 in.)
Maximum Platform Capacity
Standard w/Deck Extension
250 kg (550 lbs.) 227 kg (500 lbs.)
Maximum Number of Occupants
Standard w/Deck Extension
2 People indoors/1 person outdoors
on Extension
1 Person
Height
Working Height
6,57 m (21 ft. 7 in.) 7,79 m (25 ft. 6 in.)
Maximum Platform Height
4,57 m (15 ft.) 5,79 m (19 ft.)
Maximum Drivable Height
4,57 m (15 ft.) 5,79 m (19 ft.)
Dimensions
Weight
1343 kg (2961 lbs.) 1406 kg (3100 lbs.)
Overall Width
0,76 m (30 in.)0,76 m (30 in.)
Overall Height (Lowered)
1,89 m (74.5 in.) 2,01 m (79.25 in.)
Overall Length (Deck in)
1,75 m (68.75 in.) 1,75 m (68.75 in.)
Drive Speed
Platform Lowered
3,7 km/h (2.3 mph)
Platform Raised
1,0 km/h (0.62 mph)
Energy Source 24 V battery pack (4-220 A hour, 6 V batteries, min. wt. 26,3 kg [58 lbs.] each), 4 HP DC electric motor
System Voltage 24 V DC
Battery Charger 20 A, 110/220 VAC
Hydraulic Reservoir Capacity 12,9 L (3.4 US gal.)
Maximum Hydraulic System Pressure 207 bar (3000 psi)
Hydraulic Fluid
Normal above 0° C [32° F]
ISO #32
Low Temp. below 0° C [32° F]
ISO #32
below -17° C [0° F]
ISO #15
Lift System One Single Stage Lift Cylinder
Drive Control Motor Control
Control System Control Handle with Interlock Switch, Rotary Drive/Lift Switch, and Red Mushroom Emergency Stop Switch
Drive System Dual Front Wheel Hydraulic Motors
Tires 305 mm (12 in.) diameter solid rubber, Non-marking
Parking Brake Dual, Spring Applied, Hydraulic Release
Turning Radius (inside) 150 mm (6 in.) Inside
Maximum Gradeability 29% (16°)
Wheel Base 1,24 m (48.5 in.)
Guardrails 1,10 m (43 in.)
Toeboard 150 mm (6 in.)
Noise Level
