Upright MX19 Operator's Manual

Introduction
113100-020 - MX15 / MX19 - Operation Manual Page 3
I
NTRODUCTION
This manual covers the application of the MX Series Self-Propelled Work Platforms. This manual must be
stored on the machine at all times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
G
ENERAL
D
ESCRIPTION
WARNING
!
!
DO NOT use the maintenance platform without guardrails properly assembled and in place.
Figure 1:
MX Series
1. Platform Controls
2. Manual Case
3. Deck Extension
4. Platform
5. Elevating
Assembly
6. Chassis
7. Batteries
8. Charger Outlet
Plug
9. Chassis Controls
10. Emergency
Lowering Valve
Knob
11. Hydraulic Fluid
Reservoir
12. Lift Cylinder
13. Level Sensor
14. Depression
Mechanism
Supports
2
1
3
4
5
7
6
8
9
14
12
13
10
11
10
11
Front

Upright MX19 Specifications

General

Brand	Upright
Model	MX19
Category	Lifting Systems
Language	English
