Upright TL37 - Page 123

41
HYDRAULIC FITTING LIST
Part No. Description Qty.
13-3560 HYDRAULIC FITTING LIST (PETROL POWER) 1
13-3598 HYDRAULIC FITTING LIST (BI-FUEL) 1
12-0901 ¼” BSP Male x ¼” BSP Male Straight Adaptor 12
12-0902
3
/
8
” BSP Male x
3
/
8
” BSP Male Straight Adaptor
6
12-0903 ½” BSP Male x ½” BSP Male Straight Adaptor 1
12-1001
¼” BSP Male x
3
/
8
” BSP Male Straight Adaptor
36
12-1004
½” BSP Male x
3
/
8
” BSP Male Straight Adaptor
2
12-1005 ¼” BSP Male x ½” BSP Male Straight Adaptor 2
12-1011
¼” BSP Female Swivel x
3
/
8
” BSP Male Straight Adaptor
1
12-1105 ¼” BSP Male Equal Tee 1
12-1107 ¼” BSP Equal Tee F.O.R 6
12-1118 ¼” BSP Equal Tee F.O.B 2
12-1119
3
/
8
” BSP Equal Tee F.O.R
1
12-1210
¼” BSP Male on the Branch x
3
/
8
” BSP Male x
3
/
8
” BSP Female Unequal Tee
1
12-1501 ½” Dowty Washer 6
12-1502
3
/
8
” Dowty Washer
51
12-1507 ¼” Dowty Washer 20
12-1887 ¼” BSP Male x ¼” BSP Male Pos. Elbow 11
12-2001 ½” BSP Male Plug 2
12-2003
3
/
8
” BSP Male Plug
1
12-2004 ¼” BSP Male Plug 4
12-2010 ½” BSP Female Plug 1
12-3017 ¼” BSP Ferrule 1
12-3149 ¼” BSP Pressure Test Point 1
12-3150
¼” BSP Male x
3
/
8
” BSP Male
1
/
32
” Orifice Straight Adaptor
6
12-9000
¼” BSP Male x
3
/
8
” BSP Male 1.4mm Orifice Straight Adaptor (BI-FUEL ONLY)
4
