43
ELECTRICAL SWITCH VARIATIONS
TYPE 2 CONTACTS
Part No. Description Reference Qty.
09-0209 SWITCH BODY - 1 N.C. CONTACT PB1 & PB6 2
09-0121 SWITCH BODY - 1 N.O. CONTACT 1 ON PB2 4
1 ON PB4
1 ON PB7
1 ON SW1
09-0122 1 N.O. CONTACT BLOCK - ADD ON 1 ON PB2 6
1 ON PB7
4 ON SW1
TYPE 3 CONTACTS
Part No. Description Reference Qty.
09-1931 SWITCH BODY - 1 N.C. CONTACT PB1 & PB6 2
09-1930 SWITCH BODY - 1 N.O. CONTACT 1 ON PB4 1
09-1915 SWITCH BODY - 2 N.O. CONTACT 1 ON PB2 3
1 ON PB7
1 ON SW1
09-1932 1 N.O. CONTACT BLOCK - ADD ON 3 ON SW1 3
SWITCH HEADS
REFERENCE TYPE 1 P/N TYPE 2 P/N TYPE 3 P/N
EMERGENCY STOP PB1 & PB6 09-2004 09-0208 09-1916
BLACK PUSH BUTTON PB2 & PB7 09-2015 09-0255 09-1917
GREEN PUSH BUTTON PB4 09-2005 09-0499 09-1918
3 POSITION KEY SW1 09-2014 09-0235 09-1925
SPARE KEY FOR SW1 09-2014/1 09-1008 09-1008
