Upright TL37 - Page 44

10
Are all the
Outriggers under load? (LEDs)
Booms will not raise (Motor Running)
NO
Has the correct control switch
been selected? (ground/ basket)
YES
Select appropriate control
& Read Operators
Manual
Is the Motor Run / Deadman
being pressed?
Press the Deadman
& Read Operators
Manual
NO
YES
NO
YES
Reset the Outriggers
until all LEDs are
Illuminated
& Read Operators
Manual
Are the Hydraulics under pressure?
NO
YES
Is there enough Oil in the tank?
NO
Top up Oil Level
& Read Operators
Manual
YES
If further advice is
required, consult
an
UpRight
Technician.
A change of motor
tone can be heard.
Select appropriate control
& Read Operators
Manual
FAULT FINDING MATRIX
