11
If further advice is
required, consult
an
UpRight
Technician.
NO
YES
Are all the
Outriggers under load? (LEDs)
Booms will not lower (Motor Running)
Is there an obstruction below,
the basket or booms?
Remove obstruction, or
reposition
& Read Operators
Manual
Is the Motor Run / Deadman
being pressed?
Press the Deadman
& Read Operators
Manual
NO
YES
NO
YES
Reset the Outriggers
until all LEDs are
Illuminated
& Read Operators
Manual
Are the Hydraulics under pressure?
NO
YES
Is there enough Oil in the tank?
NO
Top up Oil Level
& Read Operators
Manual
YES
A change of motor
tone can be heard.
FAULT FINDING MATRIX
To Next Page
