Upright TL37 - Page 77

43
7 PIN PLUG
INTERIOR VIEW
RED
BLACK
YELLOW
YELLOW
L.H.
FLASHER
No. Ref. Colour Function
1
2
3
4
5
6
7
L
54G
31
R
58R
54
58L
YELLOW
BLUE
WHITE
GREEN
BROWN
RED
BLACK
L.H. Indicator
Rear Fog Lamp(s)
Earth
R.H. Indicator
R.H. Tail
Stop Lights
L.H. Tail &
Number Plate
No. Ref. Colour Function
R.H.
FLASHER
STOP
TAIL
STOP
TAIL
FOG
LIGHT
FOG
LIGHT
No. PLATE
LIGHT
1
2
3
4
5
6
7
BLUE
WHITE
WHITE
BROWN
GREEN
GREEN
BROWN
RED
WHITEWHITE
BLACK
RED
Photo show the TL37 fitted with 2 fog lights. Depending on local regulations
and specifications, your machine may be different
MAINTENANCE PROCEDURE
