Upright TL38 - Chassis Assembly

Page 6-4
Illustrated Parts Breakdown - Chassis Assembly
TL38 Service & Parts
Chassis Assembly
500001-001
ITEM
PART
NUMBER
DESCRIPTION QTY
1
500029-000 CHASSIS WELDMENT 1
2
057241-000 TOW HITCH ASSEMBLY 1
3
058242-000 JOCKEY WHEEL ASSEMBLY 1
4
500030-000 BATTERY BOX WELDMENT 1
*
500132-000 BATERY CLAMP 1
*
500052-000 HANDLE 2
*
500081-000 CATCH 2
5
057109-000 FILLER BREATHER ASSY 1
*
057379-000 GASKET (FILLER BREATHER) 1
6
057025-003 COVER, RIGHT SIDE 1
*
057025-002 COVER, LEFT SIDE 1
*
057727-000 COVER, KNOB SCREW 4
7
058116-000 BRAKE ROD 1
8
057099-000 MUDGUARD 2
9
057077-000 BRAKE CABLE ASSY 2
10
5000505-000 AXLE & BRAKE HUB ASSY 1
11
500051-000 WHEEL ASSY 2
*
500312-000 TYRE 2
*
500313-000 WHEEL ONLY 2
12
057474-000 WHEEL NUT M12 8
13
500031-000 BATTERY BOX COVER 1
14
057107-000 FILTER ASSY & HOUSING 1
15
057375-000 FILTER 1
16
504536-000 PUMP MOTOR 1
17
500032-000 OUTRIGGER WELDMENT 4
18
500033-000 OUTRIGGER FOOTPAD 4
19
500361-000 LIMIT SWITCH (O/R) 4
20
057199-000 PIVOT PIN (O/R) 8
21
058056-000 PIN LOCK PLATE 8
22
500058-000 OUTRIGGER CYLINDER 4
23
058055-002 PIN, ROD END, OUTRIGGER CYLINDER 4
24
058180-010 VALVE BLOCK ASSY, OUTRIGGER 1
25
058912-000 TILT SENSOR 1
26
057577-000 CIRCLIP 20mm 2
27
500061-000 PIVOT PIN, SMALL, FOOT PAD 1
28
500060-000 PIVOT PIN, LARGE, FOOT PAD 1
29
057032-000 CIRCLIP 35mm 2
ITEM
PART
NUMBER
DESCRIPTION QTY
