Upright TL38 - Decals Assembly

Page 6-28
Illustrated Parts Breakdown - Decal Assembly
TL38 Service & Parts
Decal Assembly
American English ANSI - 500391-000
Item Part Description QTY.
1
057421-000 DECAL - ELECTROCUTION HAZARD
2
2
057420-000 DECAL - TIP OVER HAZARD
1
3
058608-000 DECAL - LOWER CONTROL BOX
1
4
057382-000 DECAL - EMERGENCY LOWERING
2
5-- -
6
057385-000 HAZARD TAPE (900mm LONG)
8
7
058609-000 DECAL - ‘UPRIGHT’ LOGO
2
8
057339-001 PLASTIC PUSH RIVET
1
9-- -
10 - - -
11
057416-000 DECAL - BEFORE TOWING
2
12
057418-000 DECAL - LOCK OUTRIGGER TOWING
4
13
058607-000 DECAL - UPPER CONTROL BOX
1
14
058186-000 DECAL - ON/OFF UPPER CONTROL
1
15 - - -
16 - - -
17
057387-000 DECAL - UPPER QUADRAPOWER
1
18
058760-000 DECAL - MAIN INSTRUCTIONS
2
19
057430-000 DECAL - EXPLOSION HAZARD
2
20
057429-000 DECAL - BATTERY FLUID LEVEL
2
21
057417-000 DECAL - TIP OVER HAZARD
4
22
057507-010 DECAL - ARROW
2
23
058992-000 DECAL - BOOM LOCK PIN
1
24
057425-001 DECAL - SAFETY INSTR. ENCLOSED
1
25
057433-000 DECAL - FORKLIFT DAMAGE
2
26
057463-000 U.S. NAME PLATE
1
27
057427-000 DECAL - LOSS OF CONTROL
2
28
057431-000 DECAL - PERSONAL INJURY
1
29
057426-000 DECAL - SAFETY HARNESS
1
30 - - -
31
057428-000 DECAL - ANSI A92.2-1990
1
32
058538-001 DECAL - U.S. SAFETY HAZARD
1
33
057432-000 DECAL - STRUCTURAL DAMAGE
2
34
057424-000 DECAL - CRUSH HAZARD
4
35
058761-000 DECAL - S.W.L. LARGE ANSI
1
36
057434-000 DECAL - GENUINE REPLACEMENTS
1
37
057435-000 DECAL - FALL HAZARD
1
38
057422-000 DECAL - COLLISION HAZARD-BOOM
2
Decal Assembly
English CE - 500391-003
Item Part Description QTY.
1
057421-000 DECAL - ELECTROCUTION HAZARD
2
2
057420-000 DECAL - TIP OVER HAZARD
1
3
058608-000 DECAL - LOWER CONTROL BOX
1
4
057382-000 DECAL - EMERGENCY LOWERING
2
5 058860-000 DECAL - HAND HAZARD 3
6
057385-000 HAZARD TAPE (900mm LONG)
8
7
058609-000 DECAL - ‘UPRIGHT’ LOGO
2
8
057339-001 PLASTIC PUSH RIVET
1
9 058838-000 EU NAME PLATE 1
10 058836-000 VIN PLATE 1
11
057416-000 DECAL - BEFORE TOWING
2
12
057418-000 DECAL - LOCK OUTRIGGER TOWING
4
13
058607-000 DECAL - UPPER CONTROL BOX
1
14
058186-000 DECAL - ON/OFF UPPER CONTROL
1
15 058016-000 DECAL - MACHINE GENERAL INSTRUC
16 057392-000 DECAL - SWL LARGE
17
057387-000 DECAL - UPPER QUADRAPOWER
1
18 - - -
19
057430-000 DECAL - EXPLOSION HAZARD
2
20
057429-000 DECAL - BATTERY FLUID LEVEL
2
21
057417-000 DECAL - TIP OVER HAZARD
4
22
057507-010 DECAL - ARROW
2
23
058992-000 DECAL - BOOM LOCK PIN
1
