Upright TL38 - Electrical Assembly

Page 6-22
Illustrated Parts Breakdown - Electrical Assembly
TL38 Service & Parts
Electrical Assembly
500085-015
Item Part Description QTY.
1 502543-000 UPPER CONTROL BOX 1
2 502546-000 LOWER CONTROL PANEL 1
3 502548-000 TILT SENSOR 1
4 058889-000 LIMIT SWITCH (SLEW INHIBIT) 1
5 058889-000 LIMIT SWITCH (BOOM REST) 1
6 501074-000 BATTERY 4
7 502551-000 HARNESS, BATTERY INTERCONNECT 3
8 503097-000 CHARGER 1
9 501878-000 FUSE 1
10 058937-000 BATTERY DISCONNECT 1
11 502549-000
HARNESS, BATTERY DISCONNECT - BATT (-
)
1
12 502550-000
HARNESS, BATTERY DISCONNECT - BATT
(+)
1
13 058783-000 CHARGER DISCONNECT 1
14 502552-000
HARNESS, CHARGER DISCONNECT (+) -
LINE CON4
1
15 502553-000
HARNESS, CHARGER DISCONNECT (-) -
BATT (-)
1
16 502554-000
HARNESS, CHARGER DISCONNECT (-) - LINE
CON2
1
17 502555-000 LINE CONTACTOR 3 - FUSE 1
18 502556-000 LINE CONTACTOR 5 - LINE CONTACTOR 3 1
19 502489-000 LINE CONTACTOR 1
20 502557-000 LINE CONTACTOR 2 - MOTOR CONT B- 1
21 502558-000
LINE CONTACTOR 1 - MOTOR CONT
ENABLE
1
22 502559-000 LINE CONTACTOR 6 - PUMP MOTOR 1
23 502492-000 MOTOR CONTROLLER 1
24 114071-000 PUMP MOTOR 1
25 058180-010 HYDRAULIC BLOCK (OUTRIGGER) 1
26 503056-001 HYDRAULIC BLOCK (MAIN) 1
27 502547-000 ALARM 1
28 502533-000 HARNESS ASSEMBLY J1 1
29 502534-000 HARNESS ASSEMBLY J2 1
30 500361-000 LIMIT SWITCH (OUTRIGGER) 4
31 501886-000 LOAD CELL 1
* 501883-000 NYE GEL (ANTI CORROSION) 1
Item Part Description QTY.
